Packaging Automation PA210 Manual Tray Sealing Machine
top of page

Manual Range

PA 210

Image by John Cameron
Manual Range Leaflet image.png

Packaging Automation recognise the needs of small businesses who may be thinking about changing to tray sealing their products for the first time, our entry level machines are ideal for new product development, samples, or full production requirements. We know there are a lot of decisions to make and offer help and support to you get started including machine hire offers, free use of our test and development kitchen, free trials facility, advice on choosing the packaging materials, and much more.

QUICK SEARCH 210.png
Speed square icon.png

6 PPM

blue icon box 2.png
atmosphere only icon.png
ATMOS
Blue icon box 1.png
more icon.png

A compact, bench mounted hand operated machine that is ideal for new product development trials or low volume production.  It can be used to seal reel fed film or pre-cut lids to pre-formed trays.  The 210 has a maximum output of 6 cycles per minute.  Compressed air and electric supply is required for this machine.

SPIN IMAGE TO VIEW 3D

pa210 side dimension.png
pa210 front dimension.png

Electrical Supply

13A 240V 1 phase 8A

max/phase 50/60Hz

Pneumatic Supply

7cfm at 80psi



240 electrical and air.png

210 Features


Machine Features.

​

  • Simple easy operation.

  • Bench mounted and portable.

  • Automatic high accuracy sealing process.

  • Digital timer indicates the end of the required seal time.

  • Hygienic, robust construction to food industry standards.

  • Digital temperature control ensures that an accurate temperature is maintained.

  • Pressure gauge provides actual air pressure and force.

  • Adjustable seal force for better seal quality.

  • Machine can be plugged into a standard three pin household socket.

  • Sale, lease purchase and rental options tailored to suit alll requirements.

Tooling Features.

​

  • Lightweight trial tooling can be changed over in less than 4 minutes.

  • Profiled seal path for improved product presentation.

Options.

​

  • Basic rotary air compressor.

  • Can either be supplied as a 110V or 240V

  • Pharmaceutical and medical specification available.

  • Basic trial sealing tools (without film cut)for visual samples.

Materials.

​

  • The PA 210 has the ability to heat seal reel fed film, pre-cut foil, paper or laminate lids to preformed trays and containers of CPET, Polypropylene, PVC, Styrene, Board, Smooth walled foil, pre-cut board, Paper, Plastic, and many other types of container.

PA210
